Crystal Disk Info Report

Summary

Dataview displays the data retrieved by the EPM - Disk - Script - Crystal Disk Info Report script. It is not necessary for all disks to show values for all columns/properties, as different drive models can return slightly different properties/results.

Dependencies

• EPM - Disk - Script - Crystal Disk Info Report
• EPM - Disk - Custom Table - pvl_crystal_disk_info

Columns

Column	Description
clientid	Client ID (Hidden)
locationid	Location ID (Hidden)
Computerid	Computer ID
Client	Client Name
Location	Location Name
Computer	Computer Name
Operating System	Operating System
Last Logged In User	Last Logged In User
Last Contact	Last Contact with RMM
Disk ID	Disk ID
Disk Model	Disk Model
Disk Serial Number	Serial Number of the disk
Firmware	Firmware of the disk
Disk Size	Size of the Disk
Buffer Size	Buffer Size of the Disk returned by the Crystal Disk Info Tool
Queue Depth	Queue Depth of the Disk returned by the Crystal Disk Info Tool
Number of Sectors	Number of Sectors on the Disk returned by the Crystal Disk Info Tool
Rotation Rate	Rotation Rate of the Disk returned by the Crystal Disk Info Tool
Interface	Interface of the Disk
Major Version	Major Version of the Interface
Minor Version	Minor Version of the Interface
Transfer Mode	Transfer Mode(s) of the Disk returned by the Crystal Disk Info Tool
Power On Hours	Power On Hours
Power On Count	Power On Count
Host Reads	Host Reads
Host Writes	Host Writes
Wear Level Count	Wear Level Count
Temperature	Disk Temperature
Health_Status	Health Status of the Disk
Health Percentage	Life left for the disk in percentage
Features	Features of the Disk
APM Level	APM Level
AAM Level	AAM Level
Drive Letter	Drive(s) on the Disk
Script Run Time	Data Collection Time

Sample Screenshot
